YASKAWA CDBR-****D

5 Mechanical Installation
36 YASKAWA ELECTRIC TOBP C720600 01E YASKAWA AC Drive Option CDBR-D, LKEB- Installation Manual
Retrofit
Attachment
Braking Unit
CDBR-
Figure
EZZ No.
(Global Code)
Dimension mm (in)
W H D W1 H1
2022D
1
EZZ021710A
(100-066-354)
140
(5.51)
150
(5.91)
172
(6.77)
128
(5.04)
138
(5.43)
2037D
4030D
4045D
2055D
2
EZZ022243A
(100-091-605)
180
(7.09)
370
(14.57)
195.9
(7.71)
140
(5.51)
350
(13.78)
4090D
EZZ022243C
(100-091-607)
220
(8.66)
180
(7.09)
355
(13.98)
2110D
3
EZZ022243B
(100-091-606)
180
(7.09)
370
(14.57)
210
(8.27)
140
(5.51)
350
(13.78)
4220D
EZZ022243D
(100-091-608)
250
(9.84)
210
(8.27)
355
(13.98)
5300D
5110D
EZZ022243E
(100-091-609)
220
(8.66)
180
(7.09)
