YASKAWA CDBR-****D User Manual

8 Troubleshooting
YASKAWA ELECTRIC TOBP C720600 01E YASKAWA AC Drive Option CDBR-D, LKEB- Installation Manual 61
The CDBR braking unit is not
operating.
• A master unit is incorrectly set to
be a slave device and there is no
master unit.
• Incorrect braking activation switch
position.
• Properly set the CDBR braking unit
Master/Slave selection DIP switch
S2. Ensure that the master LED
(green) is illuminated on the master
CDBR unit.
• Check brake activation level switch
S3 for proper setting.
• Observe the Master and Slave
LEDs when using slave units. The
LEDs should blink when the CDBR
is activating.
The braking unit is damaged. Replace the CDBR braking unit.
Problems Cause Possible Solution
TOBP_C720600_01E_9_0_E.book 61 ページ ２０１７年８月２５日 金曜日 午後２時８分
