Install and wire the drive as explained.
Turn the power on.
Set the control mode.
Set/check the basic parameters:
b1-01, b1-02 for frequency reference and RUN command source
H1-, H2-, H3-, H4-, H6- to configure the I/Os
Frequency reference values
C1-, C2- for Acceleration/Deceleration times and S-curves
Run the motor without load, check the operation and verify, if the
upper controller (e.g. PLC,...) commands to the drive work as
desired.
Connect the load, run the motor and check the operation
Fine tune and set application parameters (e.g. PID,...) if necessary.
Final check the operation and verify the settings.
Drive is ready to run the application
START
Perform Auto-Tuning or set the motor data manually.
Initialize the drive if necessary using parameter A1-03.
Select Normal / Heavy Duty
