YASKAWA E-V Series Selection Manual

6.2 Servomotor Main Circuit Cables
6.2.1 Servomotor Main Circuit Cables for Servomotors without Holding Brakes
6-5
6
Cables and User-Assembled Wiring Materials for SGM7G Rotary Servomotors
6.2 Servomotor Main Circuit Cables
6.2.1 Servomotor Main Circuit Cables for Servomotors
without Holding Brakes
Selection Table
 SGM7G-03 or -05 (300 W or 450 W)
*1. Replace the boxes () in the order number with the cable length (03, 05, 10, 15, 20, 30, 40, or 50).
*2. These Standard Cables are Flexible Cables. The recommended bending radius (R) is 90 mm or larger.
Note: If the length of the Servomotor Main Circuit Cable exceeds 20 m, the intermittent duty zone in the torque-
motor speed characteristics will become smaller because the voltage drop increases.
 SGM7G-09 to -1E (850 W to 15 kW)
*1. Replace the boxes () in the order number with the cable length (03, 05, 10, 15, or 20).
*2. Use Flexible Cables for moving parts of machines, such as robots.
*3. The recommended bending radius (R) is 90 mm or larger.
Servomotor Model Length (L)
Order Number
*1
Standard (Flexible)
Cable
*2
SGM7G-03 or -05
300 W or 450 W
3 m, 5 m, 10 m, 15 m,
20 m, 30 m, 40 m, and 50 m
JZSP-CVM21-
-E
Servomotor Model Connector Type Length (L)
Order Number
*1
Standard Cable Flexible Cable
*2, *3
SGM7G-09 or -13
850 W or 1.3 kW
MS connector,
straight
3 m, 5 m, 10 m,
15 m, and 20 m
JZSP-UVA101-
-E JZSP-UVA121--E
MS connector,
right-angle
JZSP-UVA102-
-E JZSP-UVA122--E
SGM7G-20
1.8 kW
MS connector,
straight
JZSP-UVA301-
-E JZSP-UVA321--E
MS connector,
right-angle
JZSP-UVA302-
-E JZSP-UVA322--E
SGM7G-30
2.4 kW (When used
in combination with
the SGD7S-200A)
MS connector,
straight
JZSP-UVA601-
-E JZSP-UVA621--E
MS connector,
right-angle
JZSP-UVA602-
-E JZSP-UVA622--E
SGM7G-30 or -44
2.9 kW or 4.4 kW
MS connector,
straight
JZSP-UVA701-
-E JZSP-UVA721--E
MS connector,
right-angle
JZSP-UVA702-
-E JZSP-UVA722--E
SGM7G-55 or -75
5.5 kW or 7.5 kW
MS connector,
straight
JZSP-UVAA01-
-E JZSP-UVAA21--E
MS connector,
right-angle
JZSP-UVAA02-
-E JZSP-UVAA22--E
SGM7G-1A or -1E
11 kW or 15 kW
MS connector,
straight
JZSP-UVAB01-
-E JZSP-UVAB21--E
MS connector,
right-angle
JZSP-UVAB02-
-E JZSP-UVAB22--E
