11.1 Feedback Option Modules
11.1.1 Fully-Closed Modules
11-3
Recommended Encoders
Linear Encoders
Refer to the following section for the recommended Linear Encoder models and specifications.
9.1 Recommended Linear Encoders
on page 9-2
Rotary Encoders
Absolute Rotary Encoders
The following Absolute Rotary Encoders are for fully-closed control. Do not use it to control the
motor.
*1. The maximum speeds given in the above table are the maximum applicable speeds of the encoders when com-
bined with a Yaskawa SERVOPACK.
The actual s peed will be restricted by either the maximum speed of the Rotary Servomotor or the maximum
speed of the Rotary Encoder (given above).
*2. This is a single-turn absolute encoder.
Note: Confirm detailed specifications, such as the tolerances, dimensions, and operating environment, with the
manufacturer of the Rotary Encoder before you use it.
Output Signal Manufacturer
Rotary
Encoder
Type
Model
Resolution
Bits
Maximum
Speed
*1
[min
-1
]
Scale
Sensor
Head
Relay Device
between Fully-
Closed Mod-
ule and Rotary
Encoder
Encoder for
Yaskawa’s
Serial Interface
Magnescale
Co., Ltd.
Sealed
RU77-4096ADF
*2
– 20 2000
RU77-4096AFFT01
*2
– 22 2000
Dr. JOHANNES
HEIDENHAIN
GmbH
Exposed
ECA4412
*2
EIB3391Y 27 1600
EIB3391Y 28 800
EIB3391Y 29 400
Sealed
RCN2310
*2
EIB3391Y 26 3000
RCN5510
*2
EIB3391Y 28 800
RCN8310
*2
EIB3391Y 29 400
ROC2310
*2
EIB3391Y 26 3000
ROC7310
*2
EIB3391Y 28 800
Renishaw
PLC
Exposed
RA23Y-
*2
– 23 14600
RA26Y-
*2
– 26 3250
RA30Y-
*2
– 30 200
To Next Page
