12.2 Magnetic Contactors
12-6
12.2 Magnetic Contactors
Use a Magnetic Contactor when you configure an external AC power supply sequence.
Note: Always attach a Surge Absorber (e.g., a Surge Absorber unit) to the excitation coil of the magnetic contactor.
Consult Fuji Electric FA Components & Systems Co., Ltd. for details.
Selection Table
 Σ-7S SERVOPACKs
 Σ-7W SERVOPACKs and Σ-7C SERVOPACKs
Main Circuit
Power
Supply
SERVOPACK
Order
Number
Inquiries
Maximum
Applicable Motor
Capacity [kW]
Model
SGD7S-
Three-phase,
200 VAC
0.05 R70A
SC-03
Fuji Electric FA
Components & Systems
Co., Ltd.
0.1 R90A
0.2 1R6A
0.4 2R8A
0.5 3R8A
0.75 5R5A
SC-4-11.0 7R6A
1.5 120A
2.0 180A
SC-5-1
3.0 200A
5.0 330A
SC-N1
6.0 470A
7.5 550A SC-N2
11 590A SC-N2S
15 780A SC-N3
Single-
phase,
200 VAC
0.05 R70A
SC-03
0.1 R90A
0.2 1R6A
0.4 2R8A
0.75 5R5A SC-4-1
1.5 120A
008 SC-5-1
Single-
phase,
100 VAC
0.05 R70F
SC-030.1 R90F
0.2 2R1F
0.4 2R8F SC-4-1
Main Circuit
Power
Supply
SERVOPACK
Order
Number
Inquiries
Maximum
Applicable Motor
Capacity [kW]
Model
SGD7W-
SGD7C-
Three-phase,
200 VAC
0.2 1R6A SC-03
Fuji Electric FA
Components & Systems
Co., Ltd.
0.75 2R8A
SC-4-1
0.75 5R5A
1.0 7R6A SC-5-1
Single-
phase,
200 VAC
0.2 1R6A SC-03
0.4 2R8A SC-4-1
0.75 5R5A SC-5-1
