YASKAWA E-V Series Selection Manual

12.3 SERVOPACK Main Circuit Wires
12.3.2 Single-Phase, 200-VAC Wires for Σ-7S SERVOPACKs
12
SERVOPACK Peripheral Devices
12-13
12.3.2 Single-Phase, 200-VAC Wires for Σ-7S SERVOPACKs
SERVOPACK
Model: SGD7S-
Ter mi na l S ym bo ls Wire Size
Screw
Size
Tightening
Torq u e
[N⋅m]
R70A
Main Circuit Power
Supply Cables
L1, L2
AWG16 (1.25 mm
2
)
−−
Servomotor Main Cir-
cuit Cables*
U, V, W
Control Power Supply
Cables
L1C, L2C
External Regenerative
Resistor Cables
B1/ , B2
Ground cable
AWG14 (2.0 mm
2
) or larger
M4 1.2 to 1.4
R90A
Main Circuit Power
Supply Cables
L1, L2
AWG16 (1.25 mm
2
)
−−
Servomotor Main Cir-
cuit Cables*
U, V, W
Control Power Supply
Cables
L1C, L2C
External Regenerative
Resistor Cables
B1/ , B2
Ground cable
AWG14 (2.0 mm
2
) or larger
M4 1.2 to 1.4
1R6A
Main Circuit Power
Supply Cables
L1, L2, L3
AWG16 (1.25 mm
2
)
−−
Servomotor Main Cir-
cuit Cables*
U, V, W
Control Power Supply
Cables
L1C, L2C
External Regenerative
Resistor Cables
B1/ , B2
Ground cable
AWG14 (2.0 mm
2
) or larger
M4 1.2 to 1.4
2R8A
Main Circuit Power
Supply Cables
L1, L2, L3
AWG16 (1.25 mm
2
)
−−
Servomotor Main Cir-
cuit Cables*
U, V, W
Control Power Supply
Cables
L1C, L2C
External Regenerative
Resistor Cables
B1/ , B2
Ground cable
AWG14 (2.0 mm
2
) or larger
M4 1.2 to 1.4
5R5A
Main Circuit Power
Supply Cables
L1, L2, L3
AWG14 (2.0 mm
2
)
−−
Servomotor Main Cir-
cuit Cables*
U, V, W
AWG16 (1.25 mm
2
)
Control Power Supply
Cables
L1C, L2C
External Regenerative
Resistor Cables
B1/ , B2
Ground cable
AWG14 (2.0 mm
2
) or larger
M4 1.2 to 1.4
Continued on next page.
+
+
+
+
+
