2 Mechanical Installation
2 Mechanical Installation
 Upon Receipt
Please perform the following tasks after receiving the drive:
• Inspect the drive for damage. If the drive appears damaged upon receipt, contact your
supplier.
• Verify receipt of the correct model by checking the information on the nameplate. If you
have received the wrong model contact your supplier.
 Installation Environment
For optimum performance life of the drive, install the drive in an environment that meets the
conditions listed below.
Environment Conditions
Installation Area Indoors
Ambient Temperature
IP20/NEMA Type1 enclosure: -10 to +40C
IP20/IP00 Open-Chassis enclosure: -10 to +50C
Finless Type: IP20 enclosure: -10 to +50C
When using an enclosure panel, install a cooling fan or air conditioner in the area to
ensure that the air temperature inside the enclosure does not exceed the specified levels.
Do not allow ice to develop on the drive.
Humidity 95% RH or less and free of condensation
Storage Temperature
-20
C to +60C
Surrounding Area
Install the drive in an area free from:
• oil mist and dust
• metal shavings, oil, water or other foreign materials
• radioactive materials
• combustible materials (e.g., wood)
• harmful gases and liquids
• excessive vibration
• chlorides
• direct sunlight
Altitude 1000 m or less
Vibration
10 Hz to 20 Hz at 9.8 m/s
2
, 20 Hz to 55 Hz at 5.9 m/s
2
Orientation Install the drive vertically to maintain maximum cooling effects.

YASKAWA J1000 CIMR-JC series Specifications

General

Series	J1000
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Frequency Range	0.1 to 400 Hz
Humidity	95% RH or less (non-condensing)
Cooling Method	Fan Cooled
Enclosure Rating	IP20
Type	Variable Frequency Drive
Output Frequency	0.1 to 400 Hz
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Altitude	1000m or less above sea level
Power Supply	Single-phase or Three-phase
Input Voltage	200-240V or 380-480V
Output Voltage	0 to Input Voltage
