5 I/O Signal Allocation
5.1 I/O Module Setting
5-5
167646-1CD
HW1481264
Interface Board for Welding
Power Supply
9. The EXTERNAL IO SETUP window appears.
10. Select {AUTO} or {MANUAL} in the ALLOCATION MODE.
– The selection menu appears after selecting {AUTO} or {MANUAL}.
If the allocation mode is changed from {MANUAL} to
{AUTO}, the set allocation data is discarded. The data will
be allocated by AUTO MODE again. Save the set
allocation data to the external devices in advance, if
needed.
