2 Installation
E-22
2
Installation
Refer to the following manual for details on installing the
Machine Controller.
MP2000/MP3000 Series Machine Controller System Setup Manual
(Manual No.: SIEP C880725 00)
Precautions for the installation location are given in the fol-
lowing table.
Installation
Condition
Installation Precautions
Installation in a
control panel
• Design the control panel size, Machine Con-
troller location, and cooling method so that
the ambient temperature around the Machine
Controller does not exceed 55°C.
• If you install Machine Controllers side by
side, install a cooling fan above them.
• Provide gaps above and below the Machine
Controller.
Installation near
heat-generating
objects
Suppress temperature increases due to radiant
heat or convection from the heat-generating
object so that the ambient temperature around
the Machine Controller does not exceed 55°C.
Installation near
sources of vibra-
tion
Install a vibration-absorbing device on the
installation surface for the Machine Controller
to prevent vibration from reaching the Machine
Controller.
Continued on next page.
