5.1 Turning ON the Main Power Supply
5-1
5 Turning ON and OFF the Power Supply
5.1 Turning ON the Main Power Supply
The main power supply is turned ON when the main power supply switch on the front of the
NX100 is turned to the "ON" position, and the initial diagnosis and the current position begin.
Turning ON the Main Power Supply
• Confirm that nobody is present in the P-point maximum envelope of the
manipulator when turning on NX100 power supply.
Failure to observe this caution could result in injury caused by accidental contact with the
manipulator.
Push the emergency stop button immediately if any problems occur.
The emergency stop button is located in the upper left of the door on the NX100 and on
the right side of the programming pendant.
WARNING
kA
kVA
NJ2533-1
MADE!IN!JAPAN
TYPE
480V
SERIAL!No.
DATE
50/60Hz
INTERRUPT!CURRENT
POWER!SUPPLY
NX100/
ERCR-
3PHASE
Main!power!supply!switch
NJ1530
ＯＲＤＥＲ ＮＯ．
ON
O
F
F
WARNING
High!Voltage
with!power!ON
Do!not!open!the!
THE!MANIPULATOR!AND!CONTROLLER
SHOULD!HAVE!SAME!ORDER!NUMBER.
(Fuse!disconnect!switch)
