YASKAWA motoman NX100

7.3 CPU Unit
7-17
" Robot System Input Terminal Block (MXT)
The following signals are provided for the robot system input terminal block (MXT).
Refer to the robot system input terminal block connection diagram for the connection.
(MXT)
MXT
(MXT)
NX100!Inside!Bottom!Face
(The!figure!shows!the!bottom!face
!!of!the!NX100!inside!viewed!from
!!the!angle!looking!down!from!the
!!top.)
