YASKAWA ELECTRIC TOBP C730600 95A U1000-Series Option PS-U10 Installation Manual 9
2 Product Overview
2 Product Overview
 About this Product
The 24 V Power Supply Option supplies the drive control circuit with power when there is
no main circuit power.
The option provides external power to the control circuit only. It will not provide power to
the drive main circuit.
The option lets users access network communications, digital operator navigation, and I/O
data, and read fault and parameter data.
Note: Parameter settings cannot usually be changed without drive main circuit power regardless of
whether the control circuit has enough power to operate. However, parameter settings can be
changed when o2-19 (Selection of Parameter Write during UV) is set to 1 (Enabled).
 Compatible Drive Models
Use the option with the drive models in Table 1.
Table 1 Compatible Drive Models
Note: Compatible with models of the following software versions.
U1000: S5171 and S1017 or later
U1000 (for Crane Application): S6412 or later
U1000L: S6213 or later
Drive Option Model
U1000, U1000L
CIMR-U2 PS-U10L
CIMR-U4 PS-U10H
Z1000U
CIMR-Z2 PS-U10L
CIMR-Z4 PS-U10H
