Yealink MP50 Quick Installation Guide

1
2
x 3
x 2
100mm
74mm
148mm
99.3mm
64mm
Mounting the Screws
Yealink provides the wall mount drilling templates, which locate and
mark the position for mounting the screws (not provided) on the wall, as
shown below:
For American standard:
For others:
Attaching the Wall Mount Bracket
PC
PC
Screw position
Max:8mm
(0.315’’)
Min:6.5mm
(0.256’’)
Max:4.5mm
(0.177’’)
Screw position
Max:8mm
(0.315’’)
Min:6.5mm
(0.256’’)
Max:4.5mm
(0.177’’)

Yealink MP50 Specifications

General

HDMI Output	No
Weight	0.8 kg
Microsoft Teams	Yes
Touch Screen	Yes
Supported Video Codecs	H.264
Supported Audio Codecs	G.722, G.711
Camera	No
Microphones	Built-in microphone
Speaker	Built-in speaker
Power over Ethernet (PoE)	Yes
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
USB Ports	1 x USB 2.0
