| Introduction | 13
Port Name Description
⑧
Security Slot Creates a secure connection to the camera with a
universal security cable to lock the camera down.
UVC40
Port Name Description
①
Reset Key Resets to factory defaults.
②
DC48V port Connects to the power source via a power adapter.
③
Video Out port Connects to a PC as a video output.
④
Microphone port Connects to VCM34. It is not available in current version.
⑤
USB port (optional) Inserts DD10 to connect to CPW90. It is not available in
current version.
⑥
Line In port Connects to an audio input device using a 3.5mm audio
cable.
⑦
Security Slot Creates a secure connection to the UVC40 with a
universal security cable to lock UVC40 down.
UVC30 Room
You can use the UVC30 Room as the primary camera in the meeting room or as a content camera.
The UVC30 Room is directly connected to the MCore via USB cable.
