| Introduction |
14
MT
ouch
P
ort Name
Description
①
Human Motion
Sensor
The motion detection sensor can automatically wak
e up the
system and light up the touch screen when people approaches
the touch screen.
②
USB por
t
Connects to Mini-PC and MT
ouch is powered b
y Mini-PC.
③
3.5mm headset
jack
Connects to a headset.
13
15
