| Introduction | 19

Rear Panel of VCM38

Name Description

1 PoE Cascades multiple VCM38 units via PoE switch.

• Connects to UVC86/UVC84/UVC80/UVC50/Camera-Hub.

• Cascades multiple VCM38 units via PoE switch.

MSpeaker

Ⅱ

Port Name Description

①

DC48V Connects to the power source via a power adapter.

②

Line In port Connects to the UVC86/UVC84/UVC80/UVC50.
