Yealink MVC860 Deployment Guide

| Introduction | 24
MCore ports
• 2 x HDMI video output
• Bluetooth and Wi-Fi
• 1 x Yealink VCH port for connecting MTouch II
• 4 x USB3.0 Type-A
• 1 x 10/100/1000M Ethernet port
• 1 x Power port
• Built-in cable management
Buttons
• Mini-PC: Power On button on the front
• MCore: Power On button on the front
MTouch
• 8-inch IPS screen
• 1280 x 800 resolution
• 10-point capacitive touch screen
• 3.5mm headset jack
• Human Motion Sensor
• Angle adjustable bracket (23° ~ 50°)
MTouch
Ⅱ
• 8-inch IPS screen, 10-point capacitive touch screen
• 1280 x 800 resolution
• 3.5mm headset jack
• Human Motion Sensor
• Angle adjustable bracket (28° ~ 50°)
• 1080P/30FPS FHD
• Built-in Wi-Fi AP for Yealink wireless presentation device
• Support wired and wireless content sharing
• HDMI/USB-C HD video input
Camera-Hub
• Support up to 9 cameras
• 1 x RCA-in
• 1 x RCA-out
• 1 x Yealink Microphone port (RJ-45)
• 3 x USB 2.0 Type-A
UVC86
• 800MP, Sony Sensor
• 4K video at 30 frames out per second
• 20.4 x HD zoom (12x optical, 1.7x digital)
• Field of view (diagonal): 90°
• Pan angle range: ±100°
• Tilt angle range:
+40°，-90°
UVC84
• 4K video resolution
• 60 frame rate
• 12x optical zoom, 3x digital zoom
• Field of view (diagonal): 80°
• Pan angle range: 73°
• Tilt angle range: 45°

Yealink MVC860 Specifications

General

Bluetooth	Yes
Pan range	-100 - 100 °
Product type	Group video conferencing system
Product color	Black, Grey
Internal memory	8 MB
Tilt angle range	-90 - 40 °
Number of cameras	2
Number of persons	- person(s)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Megapixel	8 MP
Camera type	Dual camera
Sensor type	-
Digital zoom	1.7 x
Optical zoom	12 x
Combined zoom	20.4 x
Image sensor size	- \
AC input voltage	100 - 240 V
DC output current	0.7 A
DC output voltage	48 V
Power source type	AC
Processor family	Intel® Core™ i5
Operating system installed	Windows 10 IoT Enterprise
Storage media type	SSD
Total storage capacity	128 GB
Display diagonal	8 \
Touchscreen type	Capacitive
Display resolution	1280 x 800 pixels
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	6880 g
Camera weight	3270 g
Package depth	275 mm
Package width	420 mm
Package height	387 mm
Package weight	7540 g
Camera dimensions (WxDxH)	210 x 155.6 x 157.6 mm
