Yealink SIP-T23G Administrator's Guide

Audio Features
182
[1]
X is the account ID. For T57W/T54W/T48U/T48S/T48G/T46U/T46S/T46G/T29G, X=1-16; for
T53W/T53/T43U/T42G/T42U/T42S, X=1-12; for T41P/T41S/T27G, X=1-6; for T40P/T40G/T23P/T23G, X=1-3; for T21
(P) E2, X=1-2; for T19(P) E2/CP920, X=1.
[2]
If you change this parameter, the phone will reboot to make the change take effect.
Suppress DTMF Display
Suppress DTMF display allows the phones to suppress the display of DTMF digits during an active call. DTMF digits
are displayed as “*” on the phone screen. Suppress DTMF display delay defines whether to display the DTMF digits
for a short period of time before displaying as “*”.
Topic
Suppress DTMF Display Configuration
Suppress DTMF Display Configuration
The following table lists the parameters you can use to configure the suppress DTMF display.
Parameter
features.dtmf.hide <y0000000000xx>.cfg
Description
It enables or disables the phone to suppress the display of DTMF digits during an active call.
Permitted
Values
0-Disabled
1-Enabled, the DTMF digits are displayed as asterisks.
Default
0
Web UI
Features > General Information > Suppress DTMF Display
Parameter
features.dtmf.hide_delay <y0000000000xx>.cfg
Description
It enables or disables the phone to display the DTMF digits for a short period before displaying aster-
isks during an active call.
Note: It works only if “features.dtmf.hide” is set to 1 (Enabled).
Permitted
Values
0-Disabled
1-Enabled
Default
0
Web UI
Features > General Information > Suppress DTMF Display Delay
Transfer via DTMF
Call transfer is implemented via DTMF on some servers. The IP phone sends specified DTMF digits to the server for
transferring calls to third parties.
Topic
Transfer via DTMF Configuration
Transfer via DTMF Configuration
The following table lists the parameters you can use to configure the transfer via DTMF.
Parameter
features.dtmf.replace_tran <y0000000000xx>.cfg
Description
It enables or disables the phone to send designated DTMF sequences for transfer function when
pressing the Tran/Transfer soft key or TRAN/TRANSFER key.
Permitted
Values
0-Disabled
1-Enabled

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
