Yealink SIP-T41P Quick Start Guide

2
Startup
After the IP phone is connected to the network and supplied
with power, it automatically begins the initialization process.
After startup, the sign-in screen appears on the phone LED
screen. Refer to Sign-in on page 3 to sign into the Skype for
Business Server.
Welcome
Initializing...please wait
3. Connect the network and power, as shown below:
You have two options for network and power connections. Your system administrator will advise you which one to
use.
Note:
.
The IP phone should be used with Yealink original power adapter (5V/1.2A) only. The use of the third-party
power adapter may cause the damage to the phone.
If inline power (PoE) is provided, you don’t need to connect the power adapter. Make sure the hub/switch is
PoE-compliant.
Power Adapter
(DC 5V)
IEEE 802.3af compliant
PoE Hub/Switch
PC Connection
(Optional)
A
B
AC Power Option
PoE ( Power over
Ethernet ) Option
PC Connection
(Optional)

Yealink SIP-T41P Specifications

General

Power requirements	AC 100-240V, DC 5V
Power over Ethernet (PoE)	Yes
Touchscreen	-
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Voice codecs	G.711, G.723, G.726, G.729A, G.729B
Bluetooth	No
Ethernet LAN (RJ-45) ports	2
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
