Yealink SIP-T43U Getting Started

Recovery Mode on Yealink IP phones
7
1. Long press (Speakerphone key) and reconnect the power adapter to trigger the recovery
mode. Do not release until the recovery mode wizard appears on the phone LCD screen.
2. Press 1 to use the HTTP server.
3. Enter the desired values in the IP Address, Netmask, IP Gateway and HTTP Server fields
respectively.
Note
4. Press to complete the recovery mode.
The IP phone will download and upgrade the firmware from the HTTP server. After upgrading, the IP
phone will initialize successfully and get ready for use.
The LCD screen prompts “Initializing…Please Wait” when upgrading successfully.
Note
5. If the IP phone fails to upgrade, the LCD screen will indicate the failure. The user can repeat the
recovery mode procedures to try again.
For CP920 IP phones, you need to press the volume key ( or ) as the left or right
navigation key.
For SIP-T58A IP phones, you need to press / / as up/down/left/right
navigation key.
You need to press (for SIP-T58A phones), (for SIP-T3 IP phones) to complete the
recovery mode since there is no key.
…. Initializing ….
Please Wait
Welcome
IP Address:
Netmask:
IP Gateway:
HTTP Server:
10. 2. 11.124
255.255.255. 0
10. 2. 11.254
http://10.2.11.10
1

Yealink SIP-T43U Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Sustainability certificates	REACH, RoHS
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.2 W
Bluetooth version	4.1
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS, IPv6, LLDP/CDP/DHCP VLAN
USB 2.0 ports quantity	2
Lines quantity	12 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Voice codecs	AGC, AJB, AMR-NB, AMR-WB, G.711Mu, G.711a, G.723.1, G.726, G.729ab, OPUS, PLC, VAD, iLBC
Number of handles included	1 pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	206.2 mm
Width	224.9 mm
Height	174.9 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
