Yealink SIP-T43U Getting Started

Recovery Mode on Yealink IP phones
9
The IP phone must be configured in the same subnet as the TFTP server.
Note
3. Press to complete the recovery mode.
The IP phone will download and upgrade the firmware from the TFTP server. After upgrading, the IP
phone will initialize successfully and get ready for use.
The LCD screen prompts “Initializing…Please Wait” when upgrading successfully.
Note
4. If the IP phone fails to upgrade, the LCD screen will indicate the failure. You need to check and make
sure:
 The connectivity between the TFTP server and the IP phone works well.
 The resource files are correctly renamed and placed to the TFTP root directory.
 Repeat the recovery mode procedures to try again.
The LCD screen prompts “Update Fail…Please reboot” when failing to upgrade:
You need to press (for SIP-T19(P) E2 IP phones), (for SIP VP-T49G IP phones), (for
SIP-T58A/T57W IP phones), (for MP56/MP58/VP59 IP phones), (for MP54 IP phones)
(for SIP-T3 IP phones) to complete the recovery mode since there is no key.
For CP860/CP920 IP phones, you need to press the left or right side of the volume key
( )/( or ) as the left or right navigation key.
For SIP VP-T49G IP phones, you need to press / / / as up/down/left/
right navigation key.
For MP56/MP58/VP59/SIP-T58A/T57W IP phones, you need to press / / as
up/down/left/right navigation key.
For MP54 IP phones, you need to press / / as up/down/left/right
navigation key.
…. Initializing ….
Please Wait
Welcome
IP Address:
Netmask:
IP Gateway:
TFTP Server:
10. 2. 11.124
255.255.255. 0
10. 2. 11.254
10. 2. 11.123

Yealink SIP-T43U Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Sustainability certificates	REACH, RoHS
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.2 W
Bluetooth version	4.1
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS, IPv6, LLDP/CDP/DHCP VLAN
USB 2.0 ports quantity	2
Lines quantity	12 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Voice codecs	AGC, AJB, AMR-NB, AMR-WB, G.711Mu, G.711a, G.723.1, G.726, G.729ab, OPUS, PLC, VAD, iLBC
Number of handles included	1 pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	206.2 mm
Width	224.9 mm
Height	174.9 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
