Yealink SIP-T58A User Manual

SCREEN + ICONS
3
Need support? Connect with us at www.northland.net/support or
Dial 4357 (HELP) or 315-671-6262 to speak to a Northland Training Representative
The user screens and icon indicators help you navigate and understand the information on the phone’s status.
CONTROL AND NOTIFICATION CENTER
The Control Center or Notification Center provides access to certain features or notifications quickly. To access this screen swipe down
from the top of the display.
No. Name Description
1 Time and Date Displays the current time and date.
2 Control Center
Video
+ Tap to access the optional camera when the phone is idle.
+ Tap to stop transmitting video during a video call.
DND
Tap to turn DND on/off.
Forward
Tap to enter the Call Forward setting screen.
Auto Answer Tap to enter the Auto Answer setting screen.
Silent Tap to turn Silent on/off. Silences sounds such as ring tones.
Bluetooth
+ Tap to turn Bluetooth on/off.
+ Long tap to enter the Bluetooth setting screen.
Screenshot + Tap to capture a screenshot.
USB Tap to access the File Manager to manage the files in the USB flash drive.
Settings Tap to enter the Settings screen.
Backlight Drag the slider to adjust the screen brightness.
3 Notification Center
+ Tap Notification/Missed Calls/Voicemail/Forwarded to view the corresponding
notification list. These can also be viewed from the Calls List Key.
+ Tap a notification message to view details.
+ Swipe left or right to delete a specific notification.
+ Tap the trash can to delete all notifications.
4 Android Keys
Previous Screen: Tap to return to the previous screen.
Idle Screen: Tap to return to the idle screen.
Recent Applications: Tap to view and manage a list of recent applications.
1
2
3
4

Yealink SIP-T58A Specifications

General

Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Operating system version	5.1.1
Operating system installed	Android
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Bluetooth	No
Security algorithms	SRTP
Networking standards	IEEE 802.1x
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS, IPv4/IPv6, UDP/TCP/DNS-SRV
USB 2.0 ports quantity	2
Voice codecs	G.711Mu, G.711a, G.722, G.722.1, G.722.1C, G.723, G.726, G.729ab, iLBC
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Front camera resolution (numeric)	2 MP
Base station keys	27
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
Power consumption (typical)	1.9 W
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	220 mm
Width	259.4 mm
Height	239 mm
Package depth	293 mm
Package width	324 mm
Package height	128 mm
