Yealink SIP-T58W Recovery Guide

Recovery Mode on Yealink IP phones
16
Procedures
1. Long press (Speakerphone key) and reconnect the power adapter to trigger the recovery
mode. Do not release until the recovery mode selection screen appears on the phone LCD
screen.
Note
2. Press 2 on the phone keypad to use USB flash drive.
The IP phone will read and upgrade the firmware from the USB flash drive.
After upgrading, the IP phone will initialize successfully and get ready for use. The LCD screen
prompts “Initializing…Please wait” when upgrading successfully.
3. If the IP phone fails to upgrade, the LCD screen will indicate the failure. You need to check and make
sure:
 The file system of the USB flash drive should be FAT32.
 The USB flash drive has been successfully connected to the IP phone.
 The resource files are correctly renamed and placed on the USB flash drive.
 Repeat the recovery mode procedures to try again.
The LCD screen prompts “Update failed (-1)” when failing to upgrade:
4. Press to verify the current firmware version after upgrading successfully.
Note
…. Update failed (-1) ….
Welcome
.... Initializing…Please wait ….
For CP920, you need to long press the specified soft key (the second from the left on the phone)
since there is no Speakerphone key.
Press 1 to use the TFTP server. For more information on recovery mode using the TFTP server,
refer to For SIP Phone Series.
You need to tap Settings->Status (for VP59/SIP-T58A IP phones) or tap Menu->Settings (for
SIP-T57W IP phones) to verify the current firmware version since there is no key.
1. TFTP
2: USB

Yealink SIP-T58W Specifications

General

Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Video call	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	256-bit AES, HTTPS, TLS, WPA2, WPA3
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	IPv4/IPv6, SIP v1 (RFC2543), v2 (RFC3261), UDP/TCP/DNS-SRV (RFC 3263)
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	2
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Keypad number of keys	27
Number of function keys	7
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Number of handles included	1 pc(s)
Voice codecs	G.711a, G.722, G.723.1, G.726, G.729, G.729A, G.729B, iLBC

Weight and Dimensions

Depth	220 mm
Width	259.4 mm
Height	215 mm
Weight	8858 g
Package depth	293 mm
Package width	324 mm
Package height	128 mm
Package weight	9556 g
