The recommended height for camera positioning is 1.5m-1.8m above the ground
Wall Mount Method
Hole diameter: 6mm
Hole depth: 30mm
50mm
100mm
4
5 6
1
3
2 Screw specification: M3 8
+
Screw specification: T4 30
+
Steps Punch holes & Insert expansion bolts Drive screws Adjust the screws position and manually lock them
Insert screws to lock the bracket to the wall Connect DVI cable Lock the camera
1
4
3
6
2
5
5
