Yealink W53P Quick Start Guide

3
2b. (Wall-Mount Installation) Attach the base station.
3. Insert the battery into the handset.
4. Attach the belt clip to the handset.
5. (Optional) Put the handset in the protective case and attach the belt
clip.
6. (Optional) Mount the charger cradle to the wall.
E
N
G
L
I
S
H
MAC
SN
59mm
59mm
M
A
C
SN
40mm
40mm

Yealink W53P Specifications

General

Voice codecs	AMR-WB, G.722, G.726, G.729, OPUS, iLBC
Maximum range	300 m
Firmware upgradeable	Yes
Number of handsets supported (max)	8
Number of parallel conferences	3
Phonebook capacity (per handset)	800 entries
Product color	Black, Silver
Harmonized System (HS) code	85177900
Frequency range (EU)	1880 - 1900 MHz
Frequency range (US)	1920 - 1930 MHz
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Dimensions (WxDxH)	150 x 48.4 x 25 mm
