NeoGate TA400/800 User Manual
8/62
Off-hook/On-hook
Hook Description
On Hook The FXS port is idle.
Off Hook The FXS port is busy.
2.1.2 Network status
In this page, the IP address of LAN port will appear with their status.
Figure 2-2 Network Status
If your VLAN or VPN are configured, you can check the status in this page also.
2.1.3 System Info
In this page, we can check the hardware/firmware version, or the disk usage of
NeoGate TA.
Figure 2-3 System Info
