Component Location and Description
1. Touch Pad (Control Panel)
2. High Gauge
3. Low Gauge
4. Auto High Side Hose (Red)
5. Auto Low Side Hose (Blue)
6. Tank Liquid Hose (Red)
7. Tank Vapor Hose (Blue)
8. Oil Drain Bottle
9. Oil Inject Bottle
10. Tool Tray
11. Main Power Switch
12. Oil Inject Switch
13. Circuit Breaker
14. Storage Tank
15. Charge Selector Switch
16. Vacuum Pump
4
11.
4.
1.
2.
8.
5.
9.
3.
12.
10.
14.
7.
6.
13.
15.
16.
