Yeti SB165 - SB165 Frame Standards; Technical Specifications

SB165 | OWNER’S MANUAL
6
TRAVEL
165MM
WHEEL SIZE
29” FRONT, 27.5” REAR
FRAME SIZE
SM, MD, LG, XL
REAR SHOCK
230MM X 65MM
BOTTOM BRACKET
BSA 73MM
REAR WHEEL
148MM X 12MM (BOOST)
SEATPOST
31.6MM
CHAINLINE
55MM
HEADSET
INTEGRATED 41MM/52MM TAPERED
REAR BRAKE POST MOUNT
180MM
SHOCK HARDWARE
FRONT: M8X36MM REAR: CUSTOM INSERT
MIN/MAX CHAINRING
28T MIN/34T MAX
MIN MAX REAR ROTOR
180MM MIN/203MM MAX
AXLE SPEC
172MM M12X1
FRAME STANDARDS
