<5. Basic Operating Procedures>
11
IM 01E21A01-03EN-A
5.9 FOUNDATION eldbus Conguration Tool
(Not applicable for EtherNet/IP communication type. Please read the descriptions on IM 01E22A01-01EN if
necessary.)
5.10 EtherNet/IP Conguration Tool
The Ethernet conguration can connect with this product
from any connection point of RJ-45.
Port 1 and/or Port2 can be used for plant operation and
maintenance of Ethernet communication.
F0514.ai
10 / 100 M bps
PORT2 PORT1
10 /100 M bps
PORT1PORT2
PORT1 Link
/ Activity
PORT2 Link
/ Activity
Module Status
Network Status
MX
Terminal Conguration
NOTE
For maintenance (temporary connection) purpose,
connect RJ-45 Ethernet cable without passing though
the cable hole of device.
Web page can be used for conguration of EtherNet/IP
device. See IM 01E21A02-06EN for details.
Supported software
Operation systems Microsoft Windows 7 or higher
Web browser Internet explorer 8 or higher
Google chrome
Microsoft Edge
Product code/name and EDS le for EtherNet/IP
EDS le is required to connect host application tool for
EtherNet/IP (e.g. PLC). If EDS is not installed in the host
tool, download the correct EDS le from ODVA ofcial
web site and install it, or contact respective vendor of the
host tool.
EDS le is separated by the Product code/name. Conrm
the following table to install the correct EDS le.
AXG4A
Vendor ID 250
Vendor Name Yokogawa Electric Corporation
Product Code 201
Product Name AXG4A Magnetic Flowmeter
