YOKOGAWA Daqstation DX2000 User Manual

7-5
IM 04L42B01-01E
Customizing Actions Using the Event Action and Remote Control Functions (/R1 and /PM1 Options)
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
Procedure
• ResettingtheRelativeTimer
1.
In the operation mode, press FUNC.
The FUNC key menu appears.
2.
Press the Timer reset soft key.
3.
Press the softkey corresponding to timer you want to reset. Select All to reset all
timers.
The relative timer is reset.
• OperatingEventSwitches(Releasenumber3orlater)
 OperatingEventLevelSwitches
You can operate an event level switch using:
• Acustomdisplayswitch.
• Acommunicationcommand.
 OperatingEventEdgeSwitches
You can operate an event edge switch using:
• TheFUNCkey(theprocedureforoperatingtheswitchwiththeFUNCkeyis
described below).
• Acustomdisplaypushbutton.
• Acommunicationcommand.
 OperatingtheEventEdgeSwitchUsingtheFUNCKey
1.
In operation mode, press FUNC.
The FUNC key menu appears.
2.
Press the EdgeSwitch soft key.
3.
Press the switch number softkey.
The switch will turn on briefly and then turn off again.
• DisplayinganEventLevelSwitchStatusList(Releasenumber3orlater)
Display the status of the event level switch. For the operating procedure, see section
4.5.
• ResettingtheMatchTimeTimer(Releasenumber3orlater)
Operation ends when a match time timer whose timer action is set to single expires.
To use such a match time timer again, you must reset it.
1.
In operation mode, press FUNC.
The FUNC key menu appears.
2.
Press the MatchTReset soft key.
* This soft key appears when a match timer whose timer action is set to single has expired.
3.
Press the softkey with the match time timer number of the timer that you want to
reset.
The match time timer that you specify is reset.
7.1SettingtheEventActionFunction
(Includingtheremotecontrolfunctionofthe/R1and/PM1optionsandtheUSERkey)
