1-2
IM 01F06A00-01E
1. HANDLING PRECAUTIONS
(3) Mechanical Shock or Vibration
The vortex flowmeter is of sturdy construction, but
select an area subject to minimize mechanical vibrations
or impact shock. If the flowmeter is subject to vibra-
tions, it is recommended that pipeline supports to be
provided as shown in Figure 1.2.
(4) Other Considerations
• Choose a location where is sufficient clearance around
digitalYEWFLO exist to allow such work as routine
inspections.
• Choose a location that ensures easy wiring and piping.
F010301.EPS
digitalYEWFLO
Vortex Flowmeter
Pipeline
Pipeline Support
Figure 1.2
To Next Page
