AC Current Measurement [RMS] A
TY710
Rms-valuedetection,Crestfactor:<3
Range Resolution
Accuracy
Voltage Drop
Maximum Input
Current
10 to 20Hz 20Hz to 1kHz
500μA 0.01μA
1.5+20 1+20
<0.11mV/μA
440mA Protected
by a 440mA/
1000V fuse.
5000μA 0.1μA
50mA 0.001mA
<4mV/mA
500mA*3 0.01mA
5A 0.0001A
<0.1V/A
10A Protected by a
10A/1000V fuse.
10A 0.001A
AC Current Measurement [RMS] A
TY720
Rms-value detection, Crestfactor:<3
Range Resolution
Accuracy
Voltage
Drop
Maximum Input
Current
10 to 20Hz
20Hz to 1kHz 1k to 5kHz
500μA 0.01μA
1+20 0.75+20 1+30
<0.11
mV/μA
440mA Protected
by a 440mA/
1000V fuse.
5000μA 0.1μA
50mA 0.001mA
<4mV/mA
500mA*3 0.01mA
5A 0.0001A
1.5+20 1+20 2+30 <0.1V/A
10A Protected by
a 10A/1000V fuse.
10A 0.001A
Model TY710/720
Accuracy At 5 to 100% of range, At 10 to 100% of range for 10A Range
*3:Maximummeasurementcurrent:440mAat500mArange
Response time: 1 sec max.
