YOKOGAWA TY710 - Temperature Measurement

88
4.3.9 Temperature Measurement (TEMP)
CAUTION
To avoid damage to instrument
Turn off the power to the circuit under test before starting measurement in
order to prevent any excessive voltage from being applied to the instrument.
Note
Optional Temperature probe is required for temperature measurement.
TemperatureProbe:ThermocoupleTypeK
Model: 90050, 90051, 90055, 90056
Check the measurable range of respective probes.
1) Turn the function switch to the “ TEMP ” position.
2) Plug the measuring probe into the input terminals.
3)Contact the measuring probe to the under test and then read the value
when it stabilizes.
Measuring
probe
RedBlack
