105
CAUTION
To avoid damage to instrument
When the measurement function is completed, turn the function switch back to the OFF
position to turn off.
4.7 Additional functions simply set when POWER ON
With pressing the following keys, turn the function switch to the desired position of any
measurement mode (POWER ON-state).
This enables the following functions corresponding to the press keys.
Keys Functions to be set
MIN/MAX Averaging Function (calculates the average of 8 times)
RANGE 5000(3.5-digitdisplay)
SELECT LCD check (Lit only while pressing the SELECT key)
HOLD Cancels the Auto power off function
HOLD+REL
/% Reset all calibration values to those before shipment.
SELECT+RANGE Calibration function
4.8 Averaging Function
Themeasuredvaluemaygreatlyuctuate,theinstrumentcancalculatetheaverage(8times/
approx. 2 seconds).
This function is available for Voltage, Current and Resistance-mode measurement.
The function (averaging) operates until the power is turned off.
Note
Additional functions simply set when POWER ON can be used.
