Table 1. Input Signal for Calibration
Range Input 1 Input 2 Unit
DC 50mV 0.000 50.000 mV
DC 500mV 500.00 - mV
DC 2400mV 2000.0 - mV
DC 5V 5.0000 - V
DC 50V 50.000 - V
DC 500V 500.00 - V
DC 1000V 1000.0 - V

AC50mV*1 5.000 50.000 mV

AC 500mV 50.00 500.00 mV

AC5V*2 0.5000 5.0000 V

AC 50V 5.000 50.000 V

AC 500V 50.00 500.00 V

AC 1000V 100.0 1000.0 V
500Ω 0.00 500.00 Ω
5kΩ 0.0000 5.0000 kΩ
50kΩ 0.000 50.000 kΩ
500kΩ 0.00 500.00 kΩ
5MΩ 0.0000 5.0000 MΩ
50MΩ 0.000 30.000 MΩ
Continuity Check (
) 0.0 500.0 Ω
DC 500 µA 0.00 500.00 µA
DC 5000 µA 0.0 5000.0 µA
DC 50mA 0.000 50.000 mA
DC 500mA 0.00 400.00 mA
DC 5A 0.0000 5.0000 A
DC 10A 0.000 10.000 A

AC 500 µA 50.00 500.00 µA

AC 5000 µA 500.0 5000.0 µA

AC 50mA 5.000 50.000 mA

AC 500mA 50.00 400.00 mA

AC 5A 0.5000 5.0000 A

AC 10A 1.000 10.000 A
*1:FormodelTY720.
*2:FormodelTY720.Calibrationpointsaddedin5VACrange(setting,inputvalue).

[RMS], Filter OFF, Input1 (0.50000), Input2 (5.0000)

[MEAN], Filter OFF, Input1 (0.50000), Input2 (5.0000)

[RMS], Filter ON, Input1 (0.5000) , Input2 (5.0000)
50Hz/60Hz
50Hz/60Hz
