Calibration of Capacitor Range
Before start calibration of the Capacitor range,
turn the function switch back to the OFF position.
1) Turn the function switch from the OFF position to the
(Capacitor) position while
pressing the SELECT and RANGE keys at the same time.
The display shows the “ CAL ” symbol then the “ PASS ” symbol.
2) Press the SELECT key. (The display shows the “ - ” symbol.)
3) PresstheHOLDkeytwice.(Thedisplayshowsthe“---”symbol.)
4) Press the RANGE key. (The display shows the “ nF ” symbol.)
5) Connect the instrument to the calibrator with the testing leads.
6) Set the calibrator to Input 1 value as an input to the instrument.
7) PresstheHOLDkeytoconrm.
8) Set the calibrator to Input 2 value as an input to the instrument.
9) PresstheHOLDkeytoconrm.
10) Carry out calibration of other ranges by repeating steps 6) to 9).
11) To quit calibration, turn the function switch back to the OFF position.
Range Input 1 Input 2 Unit
5nF 0.500 5.000 nF
50nF 5.00 50.00 nF
500nF 50.0 500.0 nF
5μF 0.500 5.000 μF
50μF 5.00 50.00 μF
500μF 50.0 500.0 μF
5mF 0.500 5.000 mF
50mF 5.00 40.00 mF
