YOKOGAWA WT310 User Manual

v
IM WT310-02EN
Optional Accessories (Sold separately)
The following optional accessories are available for purchase separately.
For information about ordering accessories, contact your nearest YOKOGAWA dealer.
Item Model/ Min. Q’ty Note
Part No.
External sensor cable B9284LK 1 For connecting to the WT310/WT310HC/WT330’s
external current sensor input connector.
Length: 0.5 m.
Measurement lead 758917 1 Two leads in one set. Used with the 758922 or
758929 adapter (sold separately). Length: 0.75 m.
Rated voltage: 1000 V.*
Safety terminal adapter set 758923 1 Two pieces in one set. Rated voltage 600 V.*
758931 1 Two pieces in one set. Rated voltage 1000 V.*
Alligator clip adapter set 758922 1 Two pieces in one set. For use with measurement
lead 758917.
Rated voltage 300 V.*
758929 1 Two pieces in one set. For use with measurement
lead 758917.
Rated voltage 1000 V.*
Fork terminal adapter set 758921 1 Two pieces in one set. For use with measurement
lead 758917.
Rated voltage 1000 V.* Rated current: 25 A.
Conversion adapter 758924 1 BNC-4 mm socket adapter. Rated voltage: 500 V.*
* The actual voltage that can be used is the lowest voltage of the WT310/WT310HC/WT330 and
cable specifications.
Measurement
lead
758917
Alligator clip
adapter set
758922
Alligator clip
adapter set
758929
Fork terminal
adapter set
758921
Safety terminal
adapter set
758923
External sensor
cable
B9284LK
Safety terminal
adapter set
758931
Conversion adapter
758924
Checking the Contents of the Package

YOKOGAWA WT310 Specifications

General

Model	WT310
Category	Digital Power Meter
Current Measurement Range	0.5 mA to 20 A
Weight	Approx. 3.5 kg
Voltage Measurement Range	15 V to 600 V
Frequency Range	100 kHz
Basic Accuracy	0.1%
Power Accuracy	0.1%
Display	LCD
Interfaces	USB, RS-232, GP-IB
Input Elements	1
Dimensions	213 mm x 88 mm x 346 mm
