YOKOGAWA WT310 User Manual

3-4
IM WT310-02EN
3.3 Initializing the Settings
This section explains how to reset the WT310/WT310HC/WT330 settings to their factory default
values. This feature is useful when you want to cancel all of the settings that you have entered or when
you want to redo measurement from scratch.
Procedure
Follow the procedure indicated by the thick lines in the following menu.
3.
(Display C)
4.
5.
End the operation, and
if YES is selected,
initialize the settings.
Confirm that you want to
initialize the settings.
2.
Select initialization.
(Display B)
1.
Explanation
For details on initialization, see section 8.2 in the User’s Manual, IM WT310-01E.

YOKOGAWA WT310 Specifications

General

Model	WT310
Category	Digital Power Meter
Current Measurement Range	0.5 mA to 20 A
Weight	Approx. 3.5 kg
Voltage Measurement Range	15 V to 600 V
Frequency Range	100 kHz
Basic Accuracy	0.1%
Power Accuracy	0.1%
Display	LCD
Interfaces	USB, RS-232, GP-IB
Input Elements	1
Dimensions	213 mm x 88 mm x 346 mm
