YOKOGAWA WT310 User Manual

2-45
IM WT310-02EN
Making Preparations for Measurements
1
2
3
4
5
6
7
App
Index
Installing WTViewerFreePlus
Supported operating systems: Microsoft Windows XP,
1
Windows Vista,
1
and Windows 7
2
*1 32-bit versions are supported.
*2 Both 32-bit versions and 64-bit versions are supported.
Have the CD-R that contains the software ready.
If an older version of WTViewerFreePlus has already been installed, uninstall it.
There is a PDF of the manual for the software on the CD-R in the Manuals folder. To view the manual,
you need to have Adobe Acrobat Reader 5.0 or later installed.
Before you install the software, make sure that your PC meets the system requirements.
The following procedure explains how to install the software on Windows 7.
1.
Turn on the PC and start Windows. Log on as an administrator.
2.
Insert the installation disk that contains this software into the CD drive.
3.
On the PC, select the CD drive.
4.
Double-click WTViewerFreePlus_Installer.exe. The InstallShield wizard will start.
5.
Follow the instructions on the screen to install the software.
The following two items will be installed, one after the other.
• WTViewerFreePlus
• YKMUSB (USB driver)
6.
On Windows Vista or Windows 7, the “User Account Control” window will appear during the
installation. Click Allow or Yes to continue the installation.
7.
After the installation finishes, a new WTViewerFreePlus folder is added to the Start menu in
Windows. You can open the folder by clicking the Start button, All Programs, YOKOGAWA, and
then WTViewerFreePlus.
Starting WTViewerFreePlus
1.
Before you start WTViewerFreePlus, turn on the WT310/WT310HC/WT330.
2.
To start WTViewerFreePlus, click the Start button, All Programs, YOKOGAWA,
WTViewerFreePlus, and then WTViewerFreePlus. After you start WTViewerFreePlus, it will
automatically identify the WT310/WT310HC/WT330 devices that you can connect to and will
display them in the upper left of the screen.
Note
The WT310/WT310HC/WT330 will not be automatically detected if you turn it on after starting
WTViewerFreePlus.
3.
Select the WT310/WT310HC/WT330 that you want to connect to.
2.12 Connecting to a PC via USB (Installing WTViewerFreePlus)

YOKOGAWA WT310 Specifications

General

Model	WT310
Category	Digital Power Meter
Current Measurement Range	0.5 mA to 20 A
Weight	Approx. 3.5 kg
Voltage Measurement Range	15 V to 600 V
Frequency Range	100 kHz
Basic Accuracy	0.1%
Power Accuracy	0.1%
Display	LCD
Interfaces	USB, RS-232, GP-IB
Input Elements	1
Dimensions	213 mm x 88 mm x 346 mm
