YOKOGAWA ZR22G User Manual

<10. Other Functions>
10-23
IM 11M12G01-02EN 1sh Edition : Mar. 25, 2021-00
Item Initialization Parameter Default setting
Simple cell resist.
setting
Measurement mode Semi-automatic
Simple cell
resistance time
setting
Hold time [mm:ss] 01:00
Interval [day] 1
Interval [hour] 0
First start date [YY/MM/DD] 00/01/01
First start time [hh:mm] 00:00
mA output settings mA output 1 Setting items Selection of AO1 Oxygen
concentration
4-20mA point setting 4mA point 0%O2
20mA point 25%O2
Oxygen
concentration setting
Upper limit value (AO
switching)
25%O2
Output smoothing
factor
AO1 time constant 0s
Output mode Output characteristic
selections
Linear
mA output 2 Setting items Selection of AO2 Oxygen
concentration
4-20mA point setting 4mA point 0%O2
20mA point 25%O2
Output smoothing
factor
AO2 time constant 0s
Output mode Output characteristic
selections
Linear
Output hold setting Warmup Output state 4mA
Preset value 3.4mA
Maintenance Output state Last value hold
Preset value 4 mA
Cal. blowback simple
cell resist.
Output state Last value hold
Preset value 4 mA
Fault Output state Preset Value
Preset value 3.4 mA
Output limit setting Lower limit value 3.8mA
Upper limit value 20.5mA
