<5. Wiring>
5-2
IM 11M12G01-02EN 1sh Edition : Mar. 25, 2021-00
Table 5.1 Cable specications
Terminal name of converter Name Need for shields Number of cores
CELL+, CELL-
HTR TC+, HTR TC-
CJ+, CJ-
Detector signal 6
HEATER Detector heater 2
L, N Power supply 2 or 3 *
AO-1+, AO-1-, AO-2+, AO-2- Analog output 2 or 4
DO-1, DO-2, DO-3, DO-4 Contact output 2 to 8
AC-Z, AC-S, AC-C Automatic Calibration unit 3
DI-1, DI-2, DI-C Contact input 3
AI+, AI- Temperature input 2
Rs485 Rs485 3
Ether Ether (STP cable)
Note *: When the case is used for protective grounding, use a 2-core cable.
WARNING
Cables that withstand temperatures of at least 80°C should be used for wiring.
CAUTION
• Select suitable cable O.D. to match the cable gland size.
In this case, create a cable using a mixture of two types: AO, DI, or AI. Shielded cables
should be used for any mixed pattern. Never mix with other cables.
NOTE
Grounding of shielded cable
cables varies depending on the conditions of use.
FLXA402 and the connected device on the other side.
grounded.
To Next Page
