6.8 Drive mode setting
08P is the drive mode setting. The available drive modes are: 00→Pedal assist only, 01→Electric only, 02→Both
Pedal assist and electric.
Press to enter the parameter changing state. Press the / to select the parameter and press to save the
parameter setting and return to the personalized parameter setting interface.
Figure 6-8 Drive mode setting interface
6.9 Pedal assist sensitivity setting
09P is the pedal assist sensitivity setting. When set to higher numbers, it will take more crank rotations to activate the
motor. On lower numbers, it will take little crank rotation to activate the motor. The adjustable range is: 1~24.
Press to enter the parameter changing state. Press the / to select the parameter and press to save the
parameter setting and return to the personalized parameter setting interface.
Figure 6-9 Pedal assist sensitivity setting interface
