Yongnuo YN568EX User Manual

5. Shooting Examples with Wireless Flash System
z Master unit: 580-II, SB-900/800/700, 7D/60D/600D with built-in commander mode, Nikon c-commander
and ST-E2.
z Slave unit: YONGNUO EX series flash, you can create three slave groups at all.
z Use the mini flash stand (tripod socket provided) to prop up the YN568EX speedlite.
z Swing the YN568EX so that its wireless sensor faces the master unit.
z Indoors, the wireless signal can also bounce off the wall so there is more leeway in positioning the
YN568EX(s).
z After positioning the YN568EX(s), be sure to test the wireless flash operation before shooting.
z Don’t place any obstacles between the master unit and slave unit(s). Obstacles can block the transmission of
wireless signals.
VIII. The Andvanced Application
1. High-speed sync Flash
With high-speed sync (FP flash), the YN568EX can synchronize with all
shutter speeds, the maximum shutter sync up to 1/8000. Setting method:
Press the [High-speed /rear-curtain sync] button to select HSS.

Yongnuo YN568EX Specifications

General

Flash Modes	TTL, Manual, Multi
Zoom Range	24-105mm
Recycle Time	Approx. 3 seconds
Power Source	4 x AA batteries
High-Speed Sync	Yes
Color Temperature	5600K
Swivel Angle	270 degrees
Guide Number	58 (at ISO 100, 105mm)
Vertical Rotation Angle	-7 to 90 degrees
Horizontal Rotation Angle	0 to 270°
Compatible Cameras	Canon or Nikon (depending on the version)
Tilt Angle	-7 to 90 degrees
Wireless Functionality	Yes, Master & Slave (Canon & Nikon)
Weight	380g (without batteries)
