Yongnuo YN568EX User Manual

V. Installation Instruction
1. Install Batteries
Slide the batteries chamber’s cover in the direction of the arrow.
Insert the batteries according to the label inside battery chamber.
Make sure the direction of the batteries’ polarity is correct.
Close the battery chamber cover in the direction of the arrow.
2. Attaching to the Camera
Loosen the locking ring by turning it in the direction of the arrow.
Slip the speedlite hot shoe stand into the camera hot shoe stand until it stops.
Turn the locking ring in the direction of the arrow tighten.
To detach the speedlite, loosen the locking ring by turning it in the opposite direction.

Yongnuo YN568EX Specifications

General

Flash Modes	TTL, Manual, Multi
Zoom Range	24-105mm
Recycle Time	Approx. 3 seconds
Power Source	4 x AA batteries
High-Speed Sync	Yes
Color Temperature	5600K
Swivel Angle	270 degrees
Guide Number	58 (at ISO 100, 105mm)
Vertical Rotation Angle	-7 to 90 degrees
Horizontal Rotation Angle	0 to 270°
Compatible Cameras	Canon or Nikon (depending on the version)
Tilt Angle	-7 to 90 degrees
Wireless Functionality	Yes, Master & Slave (Canon & Nikon)
Weight	380g (without batteries)
