Assembly instructions
N-8
x 8
ALLEN BOLT
(M8 X P1.25 X 16L)
N-2
x 1
METAL COVER
N-9
x 8
REGULAR WASHER
(Ø8 X 19 X 2T)
N-4
x 2
SPRING WASHER
(Ø7)
ALLEN KEY X 1
T-SHAPE KNOB (M7 X 65L) X 1
SCREWDRIVER X 1
BOX SPANNER X 1
N-3
x 2
REGULAR WASHER
(Ø7)
N-5
x 1
ALLEN BOLT
(M7 X P1.0 X 30MM)
N-7
x 1
BUSHING
(Ø12 X 40MM)
N-1
x 1
SCREWS
(M3 X 25MM)
Prepare your work area - It is important you assemble the product in a clean and uncluttered space.
Work with a friend - We recommend you have someone assist you with the assembly as some of
the components are quite heavy.
Open the carton - Check any warnings on the carton and make sure you have it the right way up.
Unpack the carton - Remove all the parts and lay them out on the floor.
Make sure you have the following parts:
Care & Maintenance
• This equipment should not be placed outdoors, in a garage or an outbuilding. Keep the
equipment in a dry place with as little temperature variation as possible.
• We recommend placing a mat beneath the equipment to protect both the equipment and
your flooring.
• Alwaysplacetheequipmentinadryenvironment.
• Useawarm,dampclothtokeeptheproductclean.
• Nowetcleaningofelectricalcomponents.Unplugbeforeanycareandmaintenance.
• Thesafetyleveloftheequipmentcanbemaintainedonlyifitisregularlyexaminedfor
damageandwear.Thisincludesanyropes,pulleys,nuts,bolts,movingparts,bushes,
chains,wheels,bearings&connectionpointsetc.
• Ensurethatyouinspecttheproductregularly-atleastonceaweekisrecommended.
• Ensurethatallxingsaretightbeforeuse.
• Alwaysreplacedamaged/worncomponentswithoriginalpartsfromthemanufacturer.
