268723-BIM-C-0908
10 Johnson Controls Unitary Products
Figure 8: Typical Field Power Wiring Diagram
Table 5: Electrical Data
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Electric Heat Option
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA Model kW Stages Amps
024
(2.0)
208/230-1-60 12.8 60 20 1.2 4.1
None - - - 21.3 30
2NH04500506 3.8 / 5 1 18.1 / 20.8 43.9 / 47.3 50 / 50
2NH04500706 5.6 / 7.5 2 27.1 / 31.3 55.2 / 60.4 60 / 70
2NH04501006 7.5 / 10 2 36.1 / 41.7 66.4 / 73.4 70 / 80
030
(2.5)
208/230-1-60 14.7 73 23 1.2 4.1
None - - - 23.7 30
2NH04500506 3.8 / 5 1 18.1 / 20.8 46.2 / 49.7 50 / 50
2NH04500706 5.6 / 7.5 2 27.1 / 31.3 57.5 / 62.7 60 / 70
2NH04501006 7.5 / 10 2 36.1 / 41.7 68.8 / 75.8 70 / 80
2NH04501506 11.3 / 15 2 54.2 / 62.5 91.4 / 101.8 100 / 110
208/230-3-60 10.4 60 16 0.8 4.1
None - - - 18.3 25
2NH04501025 7.5 / 10 1 20.8 / 24.1 44.4 / 48.4 45 / 50
2NH04501525 11.3 / 15 1 31.3 / 36.1 57.4 / 63.4 60 / 70
460-3-60 4.5 31 7 0.8 2.1
None - - - 8.5 15
2NH04501046 10 1 12 23.5 25
2NH04501546 15 1 18 31 35
036
(3.0)
208/230-1-60 15.4 83 24 1.2 6.0
None - - - 26.5 35
2NH04500506 3.8 / 5 1 18.1 / 20.8 49 / 52.5 50 / 60
2NH04500706 5.6 / 7.5 2 27.1 / 31.3 60.3 / 65.5 70 / 70
2NH04501006 7.5 / 10 2 36.1 / 41.7 71.6 / 78.5 80 / 80
2NH04501506 11.3 / 15 2 54.2 / 62.5 94.2 / 104.6 100 / 110
208/230-3-60 11.5 77 18 1.2 6.0
None - - - 21.6 30
2NH04501025 7.5 / 10 1 20.8 / 24.1 47.6 / 51.6 50 / 60
2NH04501525 11.3 / 15 1 31.3 / 36.1 60.7 / 66.7 70 / 70
460-3-60 5.1 35 8 0.8 3.0
None - - - 10.1 15
2NH04501046 10 1 12 25.2 30
2NH04501546 15 1 18 32.7 35
042
(3.5)
208/230-1-60 18.6 105 29 1.2 6.0
None - - - 30.5 40
2NP04501006 7.5 / 10 2 36.1 / 41.7 75.6 / 82.5 80 / 90
2NP04501506 11.3 / 15 2 54.2 / 62.5 98.2 / 108.6 100 / 110
2ND04501506
3.8 / 5 1 18.1 / 20.8 53 / 56.5 60 / 60
7.5 / 10 1 36.1 / 41.7 75.6 / 82.5 80 / 90
208/230-3-60 13.4 88 21 1.2 6.0
None - - - 24 30
2NP04501025 7.5 / 10 1 20.8 / 24.1 50 / 54 60 / 60
2NP04501525 11.3 / 15 1 31.3 / 36.1 63 / 69.1 70 / 70
460-3-60 6.4 39 10 0.8 3.0
None - - - 11.8 15
2NP04501046 10 1 12 26.8 30
2NP04501546 15 1 18 34.3 35
048
(4.0)
208/230-1-60 21.1 113 33 1.2 6.0
None - - - 33.6 45
2NP04501006 7.5 / 10 2 36.1 / 41.7 78.7 / 85.7 90 / 90
2NP04501506 11.3 / 15 2 54.2 / 62.5 101.3 / 111.7 110 / 125
2NP04502006 15 / 20 2 72.2 / 83.3 123.9 / 137.7 125 / 150
2NP04502506 18.8 / 25 2 90.3 / 104.2 146.4 / 163.8 150 / 175
208/230-3-60 16.0 120 25 1.2 6.0
None - - - 27.2 35
2NP04501025 7.5 / 10 1 20.8 / 24.1 53.3 / 57.3 60 / 60
2NP04501525 11.3 / 15 1 31.3 / 36.1 66.3 / 72.3 70 / 80
2NP04502025 15 / 20 2 41.7 / 48.1 79.3 / 87.3 80 / 90
2NP04502525 18.8 / 25 2 52.1 / 60.1 92.4 / 102.4 100 / 110
460-3-60 8.3 60 13 0.8 3.0
None - - - 14.1 20
2NP04501046 10 1 12 29.2 30
2NP04501546 15 1 18 36.7 40
2NP04502046 20 2 24.1 44.2 45
2NP04502546 25 2 30.1 51.8 60
