York BUZ024 - Dimensional Details; Dimensions Front and Bottom; Dimensions Back and Bottom

268723-BIM-C-0908
6 Johnson Controls Unitary Products
Figure 4: Dimensions Front and Bottom
Figure 5: Dimensions Back and Bottom
6
FRONT
26-3/4
CONDENSATE
DRAIN 3/4" NPTF
LOW VOLTAGE
CONN. 7/8" DIA.
KNOCKOUT
HIGH VOLTAGE
CONN. 1-31/32" x 7/8"
KNOCKOUT
22-1/2
43-1/2
40-1/2
4
14-1/2
28-3/8
14-1/2
BACK
3-3/8
SIDE RETURN
AIR OPENING
14-1/2
3-1/2
3-1/2
15
1-3/4
1-3/4
BOTTOM RETURN
AIR OPENING
15
28-9/16
15
1-3/4
BOTTOM SUPPLY
AIR OPENING
CONDENSER
COIL
SIDE SUPPLY
AIR OPENING
