York CIW01 - Page 11

P5415484
11
No. Items Optional Function
Individual
Setting
Setting
Condition
Contents Setting
29 CF Change of Louver Swing Angle
○
00
01
02
< Wall Mounted Type >
Standard (7-Step Operation)
(5 steps for cooling / dry mode)
Cold Draft Prevention
(5 Steps: lower 2 steps cut off)
(Heating and fan only)
Not Used
00
01
02
< Other than Wall Mounted Type with louvers >
Standard (7-Step Operation)
Cold Draft Prevention
(5 Steps: lower 2 steps cut off)
High Ceiling (higher 2 steps cut off)
30 d1 Power Supply ON/OFF 1
○
00
01
Not Available
Available
31 d2 Not Prepared - - Not Used
32 d3 Power Supply ON/OFF 2
○
00
01
Not Available
Available
33 d4
Prevention for Cooling Discharge Air
Temp. Decrease (*4)
○
00
01
Not Available
Available
34 d5
Prevention for Heating Discharge Air
Temp. Decrease
○
00
01
Not Available
Available
35 d6 Not Prepared - - Not Used (Use as 00 setting conditions)
36 d7 Not Prepared - - Not Used
37 E1 Not Prepared - - Not Used (Use as 00 setting conditions)
38 E2 Not Prepared - - Not Used (Use as 00 setting conditions)
39 E3 Not Prepared - - Not Used (Use as 00 setting conditions)
40 E4 Not Prepared - - Not Used (Use as 00 setting conditions)
41 E5 Not Prepared - - Not Used (Use as 00 setting conditions)
42 E6
Indoor Fan Operation Time After
Cooling Operation Stoppage
○
00
01
02
Not Available
60 min.
120 min.
43 E7 Not Prepared - - Not Used (Use as 00 setting conditions)
44 E8
Fan Operation Control during
Heating Thermo-OFF
○
00
01
Not Available (LOW)
SLOW
45 E9 Not Prepared - - Not Used (Use as 00 setting conditions)
46 EA Not Prepared - - Not Used (Use as 00 setting conditions)
47 Eb
Fan Operation Control during
Cooling Thermo-OFF
○
00
01
02
Not Available
LOW
SLOW
48 EC
Forced Thermo-ON Stoppage during
Cooling
○
00
01
Not Available
Available
49 Ed Not Prepared - - Not Used (Use as 00 setting conditions)
50 EE Automatic Fan Speed Control
○
00
01
Not Available
Available
51 EF
Automatic Fan Speed Control
(High 2)
○
00
01
Not Available
Available
52 F0 Not Prepared - - Not Used
53 F1 Automatic OFF Timer Setting
* Do not set the functions “0C”~“0F”
when 2 (two) wired controllers are
used in the same controller group.
×
00
01
02
•
•
23
24
0A
0B
0C
0D
0E
0F
No Function
OFF Timer by 1 hr
OFF Timer by 2 hrs
•
•
OFF Timer by 23 hrs
OFF Timer by 24 hrs
OFF Timer by 30 min.
OFF Timer by 90 min.
OFF Timer by 40 min.
OFF Timer by 45 min.
OFF Timer by 50 min.
OFF Timer by 55 min.
}
Do not set them when
two wired controllers
are used.
