YORK INTERNATIONAL
OPERATING LIMITATIONS AND SOUND POWER DATA
SOUND POWER DATA (PRELIMINARY)
MODEL Lwa
YCAS dBA
0283EC 102
0303EC 102
0323EC 104
0343EC 104
OPERATING LIMITATIONS – SI UNITS
* Maximum Ambient w/ High Ambient Kit is 54°C.
MIN MAX
LEAVING CHILLED LIQUID TEMP ( °C) 4.5 15
CHILLED WATER TEMP DIFFERENCE ( °C) 310
WATER SIDE PRESSURE (BAR) –10
REFRIGERANT SIDE PRESSURE (BAR) –20
MINIMUM PRIMARY COOLER FLOW
MODEL WATER VOLUME LITERS/SECOND
YCAS (LITERS) MIN. MAX.
0283EC 2570 7.1 37.9
0303EC 2748 7.7 37.9
0323EC 2983 8.0 37.9
0343EC 3259 8.4 37.9
AIR STANDARD FANS –18 46
ENTERING HIGH PRESS. FANS –18 46
CONDENSER (
°°
°°
°C) SLOW SPEED FANS –18 46
FAN STANDARD FANS 20
AVAILABLE STATIC HIGH PRESS. FANS OPTION 1 85
PRESSURE (Pa) HIGH PRESS. FANS OPTION 2 150
SLOW SPEED FANS 10
ELECTRICAL THREE PHASE 50 Hz (V) 380 415
